Center Surface Slitter Rewinder



Center Surface Slitter Rewinder

This is a surface winding slitting machine.This model is a perfect and ideal machine for slitting small scale and narrow materials.The main motor adopts variable frequency speed regulation,to use the constant tension magnetic powder control,auto photoelectric edge correction, two units of magnetic powder clutch on rewinding,blocking with main motor,control(barometric pressure)the central volume reeling and with contact the surface,the two axle inter rewinding, never nips the mouth,and have the meter preset,auto stop functions.





1. Chassis under machine and sides of baffle adopted channel steel weld construction.

2. Unwinding auto tension adopted 10kg magnetic powder Brake 1pcs.

3. Rewinding auto tension adopt 5kg magnetic powder Clutch 2pcs.

4. Rewind device adopts 25mm and 76mm airshaft 2pcs,and adopts 1 pcs of airshaft on unwind device,and 1 pcs of mechanical shaft .

5. Unwinding adopt photoelectric eye correcting the error,and have the auto meter counting, auto stop functions.

6. Slitting device equiped 12 sets knives .

7. The main motor Main motor drive with 5.5KW motor,frequency speed regulating (Yaskawa).

8. All the gears and chains on this machine adopt hardness thermal refining.

9. Waste material processing adopt one set 0.55KW centrifugal blower.

10. Spare parts together with machine is spanner wrench one set ,one English manual.





QFJ600B Center Surface Slitter Rewinder





TYPE	QFJ600B
Max.width of material	600mm
Speed of machine:	160m/min
Max.diameter of material:	φ600mm
Rewind Diameter:	φ420mm
Minimum width:	6-600mm
Precision:	±0.3mm
Total power:	6.5KW

Correct specifications depend on the actual model. All specifications are subject to change without prior notice.
